ENVIRONMENTAL SPECIFICATION 23
Chapter 1
Resetting the Power Supply
If an overload triggers the power supply overload protection, all power is immediately cut. To reset the
power supply unit:
1 Disconnect the power cord.
2 Determine what caused the overload and fix the problem.
3 Reconnect the power cord and reboot the workstation.
When you power down the workstation through the operating system, power consumption falls below the
low power consumption but does not reach zero. This on/off feature extends the life of the power supply.
Environmental Specification
PCI and PCI Express Slot Power Specifications
The following table describes the slots, card types, and maximum slot power.
Table 1-9 Environmental Specifications
Temperature (operating) 40° to 95° F (5° to 35° C)
Temperature (non-operating) -40° to 140° F (-40° to 60° C)
Humidity (operating) 8% to 85% RH, non-condensing
Humidity (non-operating) 8% to 90% RH, non-condensing
Shock (operating) 1/2-sine: 40G, 2–3ms
Shock (non-operating) 1/2-sine: 160 cm/s, 2–3ms, (~100g)
square: 20G, 422 cm/s
Vibration (operating) Operating random: 0.5G(RMS), 5–300Hz
Vibration (non-operating) Random: 2.0g(RMS), 10–500Hz
Maximum Altitude (operating) 0–10,000 ft (3,048 m)
Maximum Altitude (non-operating) 0–30,000 ft (9,144 m)
Table 1-10 PCI and PCI Express Slot Power Specifications
Slot# Slot Type Slot Power (Maximum)
1 PCI 10 W*
2 PCI Express x16 graphics 150 W**
3 PCI 25 W*
4 PCI Express x8’ (x4 performance) 25 W*
5 PCI-X 133 25 W*
