REMOVAL AND REPLACEMENT OF COMPONENTS 71
Chapter 4
Access Panel
Before accessing the internal components of the workstation, the access panel must be removed.
To remove the access panel:
WARNING! Before removing the workstation access panel, be sure that the workstation is turned off
and that the power cord is disconnected from the electrical outlet.
1 Disconnect power from the system (page 66).
2 If necessary, unlock the access panel (page 69 or page 70). The keys are on the rear panel
(page 18).
3 Pull up on the handle and lift off the cover.
To replace the access panel, slide the cover back on until it snaps into place.
Front Bezel
To remove the bezel:
1 Lift up on the three 1 tabs located on the front bezel.
