162 CONNECTOR PINS
24-Pin Power (Main)
6-Pin Power (Auxiliary System Board)
CAUTION Be sure you can differentiate which power cable connects to the PCI Express x16 graphics card
and which power cable connects to the system board. These two cables look very similar. The PCI Express
power cable has a black connector and the power cable has a white connector. When power is present, you
must NEVER connect the PCI Express power cable to the system board. If you do so, the system board may
be damaged and your warranty voided. To see a picture of the PCI Express cable and where it must be
connected, refer to the “PCI or PCI Express Installation” section on page 84.
24-Pin Main Power Connector
1
2
3
4
5
6
7
+3.3 V
+3.3 V
GND
+5 V
GND
+5 V
GND
8
9
10
11
12
13
POK
+5 Vaux
+12 V-A
+12 V-A
+3.3 V
+3.3 V and
+3.3V-Rsense
14
15
16
17
18
19
20
-12 V
GND
PS_ON_L
GND
GND
GND
21
22
23
24
+5 V
+5 V and
+5 V-Rsense
+5 V
GND
6-Pin Power (Auxiliary System Board) Connector Pin Color Signal
1ORG+3.3V
2ORG+3.3V
3 YEL +12V-A
4BLKGND
5BLKGND
6 YEL -12 V
112
13 24
46
3
1
