18 PRODUCT OVERVIEW
Rear Panel Components
Table 1-3 Rear Panel Components
1 Universal Chassis Clamp Opening 10 Graphics Adapter
2 Access Panel Keys 11 Microphone Connector (pink)
3 Padlock Loop 12 IEEE 1394 Connector
4 Cable Lock Slot 13 USB (x6)
5 PS/2 Mouse Connector (green) 14 Serial Connector (teal)
6 Parallel Connector (burgundy) 15 PS/2 Keyboard Connector (purple)
7 RJ-45 Network Connector 16 Built-In Self Test (BIST) LED
8 Audio Line-In Connector (light blue) 17 Power Cord Connector
9 Audio Line-Out Connector (lime)
NOTE: To assist you in connecting your peripheral devices, the rear panel connectors are labeled and color-coded according to
industry standards.
11
12
13
14
15
16
1
3
4
8
9
10
17
5
6
7
2
