Appendix E
Appendix E System Board Designators
This appendix lists the system board designators for this system.
Table E-1 System Board Designators
Designator Silkscreen Component
MH01, MH04-MH09 N/A Mounting holes
N/A N/A LED: 5V_AUX power indicator
N/A N/A Power LED
J104 N/A Boot block header/jumper
J64 PSWD Clear password header/jumper
J20 SLOT3 PCI PCI slot
J21 SLOT1 PCI PCI slot
J22 SLOT5 PCI-X 133 PCI slot
J23 SLOT6 PCI-X 100 PCI slot
J24 SLOT7 PCI-X 100 PCI slot
J31 SLOT4 PCI-E X8 PCI Express slot
J37 SCSI1 Primary SCSI connector
J38 SCSI2 Secondary SCSI connector
J41 SLOT2 PCI-E X16 GRAPHICS PCI Express x16 slot for graphics
J50 PAR/SER Parallel port
P10 KBD MS PS2 Stacked keyboard/mouse connector
J9 RJ45/USB Stacked RJ45/Dual USB
J10 USB1 Quad stacked USB
J11 1394 IEEE 1394 connector
J83 AUD Triple stacked audio jack
SW50 N/A Reset header
P1 PWR Power supply connector (24 pin)
