166 SYSTEM BOARD DESIGNATORS
P2 PWR2 Second power supply connector
P3 PWRCPU Processor 12V header
J32 FDD Diskette drive connector
J101 SECURITY Security board connector
P7 CD CD analog audio connector
P11 AUX Auxiliary audio connector
P20 PRIMARY IDE Primary IDE connector
P21 SECONDARY IDE Secondary IDE connector/Multi-Bay
connector
P23 FRNT AUD Front panel audio header
P24 FRNT USB Front panel USB header
P27 MBAY Multi-Bay header
P29 HDD LED HDD LED connector
P50 SATA Primary serial ATA (SATA) connector
J59 CONTROL PANEL Main power/HDD LED connector
P53 N/A Serial port
P70 CPU1FAN Primary CPU fan header
P71 CPU2FAN Secondary CPU fan header
P8 SYS FAN Primary chassis fan header
P9 PCI FAN Secondary chassis fan header
J63 CLR CMOS Clear CMOS switch/push button
XBT XBT1 Battery retainer
U13 DIMM1 Memory slot
U9 DIMM2 Memory slot
U12 DIMM3 Memory slot
U8 DIMM4 Memory slot
U11 DIMM5 Memory slot
U7 DIMM6 Memory slot
U10 DIMM7 Memory slot
U6 DIMM8 Memory slot
Table E-1 System Board Designators
Designator Silkscreen Component
