20 PRODUCT OVERVIEW
Power Supply and Cooling
The workstation has 9 outputs:
 +3.3V—used with PCI, MCH, ICH5, PXH, LAN, SATA and SCSI hard drives, and on-board logic
 +5V—used with storage (disk, optical, diskette), PCI, Audio, USB, input to on-board regulator, and
on-board logic
 +12V-A—used with PCI, fans, input to onboard regulators that supply 1.2V, 1.5V, and 1.8V
 +12V-B—used with storage (disk, optical, floppy)
 +12V-C—used with PCI Express x16 auxiliary connector
 +12VCPU0—input to onboard regulator that supplies power for CPU0
 +12VCPU1—input to onboard regulator that supplies power for CPU1
 -12V—used by PCI
 5VSB—used for sleep circuitry
Table 1-5 Power Supply and Cooling (Voltage)
Voltage Minimum Maximum
3.3 V 3.17 V 3.47 V
5 V 4.85 V 5.25 V
12 VCPU0 11.52 V 12.6 V
12 VCPU1 11.52 V 12.6 V
12 V-A 11.52 V 12.6 V
12 V-B 11.52 V 12.6 V
12 V-C 11.52 V 12.6 V
V12N -11.4 V -12.6 V
5 VSB 4.85 V 5.25 V
Table 1-6 Power Supply and Cooling (Current)
Current Minimum Operating Continuous Maximum
3.3 V 0 A 3.1 A 28 A 35.0 A
5 V 0 A 2.3 A 19.9 A 25.0 A
12 VCPU0 0 A 3.1 A 11.4 A 13.7 A
12 VCPU1 0 A 0 A 11.4 A 13.7 A
12 V-A 0 A 0 A 9 A 11.6 A
