REMOVAL AND REPLACEMENT OF COMPONENTS 69
Chapter 4
Disassembly Order
Use the following table to determine the sequence in which to remove the major components.
Security Lock (Optional)
If a security padlock is installed, remove it before servicing the unit. To remove the padlock, unlock it and
slide it out of the padlock loop as shown in the following image.
Pre-Disassembly (page 66)
Locks (page 69)
Access Panel (page 71)
Hood Sensor (page 72)
Front Bezel (page 71)
Front Panel I/O Device Assembly
(page 73)
Power Button and Front
Speaker (page 74)
Optical Drive (page 87)
Diskette Drive (page 89)
Bezel Blanks (page 72)
Power Supply (page 74)
System Fan (page 75)
Memory (page 76)
Front Fan Removal
(Optional) (page 85)
Battery (page 86)
Hard Drive (page 91)
CPU Heatsink (page 96)
Processor (page 99)
PCI Card Support (page 81)
PCI Retainer (page 83)
PCI or PCI Express card (page 84)
CPU Heatsink (page 96)
Processor (page 99)
System Board (page 101)
To Next Page
