POWER SUPPLY AND COOLING 21
Chapter 1
WARNING! Do not exceed 135 W of a 5 V and 3.3 V power combination.
WARNING! Do not exceed 43 A (516 W) of 12 V (CPU0/CPU1/A/B/C) power combination.
WARNING! Do not exceed 600 W of total continuous output power.
Power Supply Specifications
12 V-B 0 A 0 A 3.8 A 11.7 A
12 V-C 0 A 0 A 7.1 A 11.8 A
V12N 0 A 0 A 0.5 A 0.8 A
5 VSB 0 A 0 A 1.5 A 2 A
Table 1-7 Power Supply Specifications
Full Ranging Input (No Line Select Switch) Yes
Active Power Factor Correction (APFC) (Input Current is nearly
1/2 a non-APFC PS)
Yes
Passive Power Factor Correction (PFC) No
Operating Voltage Range 90 - 264 VAC / 118 VAC
Rated Voltage Range 100 -240 VAC
Rated Line Frequency 50-60 Hz / 400Hz
Operating Line Frequency Range 47 - 66 Hz / 393 - 407Hz
Rated Input Current 10A / 8.6A
Maximum Rated Power 600 W
Heat Dissipation Typical 1206.2 btu/hr
Maximum 3150.5 btu/hr
Power Supply Fan 92mm variable speed
PS Size (wide x high x deep) 98mm x 160mm x200mm
ENERGY STAR Compliant Yes
Table 1-6 Power Supply and Cooling (Current)
Current Minimum Operating Continuous Maximum
