88 REMOVAL AND REPLACEMENT PROCEDURES
NOTE The audio cable is only required for Linux-based systems.
3 Lift the green drivelock release lever and gently slide the drive out of the chassis.
To replace an optical drive:
1 Lift the green drivelock release lever while sliding the optical drive into the bay. When the optical drive
is partially inserted, release the drivelock release lever and slide the drive completely into the bay
until the drive is secured.
CAUTION Ensure that the optical drive is secure. Failure to do so can cause damage to the drive when
moving the workstation.
2 Connect the power, drive, and audio (if required) cables to the drive and workstation.
NOTE The audio cable is only required for Linux-based systems.
