SSD–Solid-state drive
TSG–Troubleshooting Guide
UEFI–Unied Extensible Firmware Interface
WLAN–Wireless local area network
WWAN–Wireless wide area network
Blinking lights and boot error codes
The information below is from the white paper http://h10032.www1.hp.com/ctg/Manual/c04685655.
In some cases, when the host processor is not executing code or does not have the necessary code to drive the
display, light blink codes inform you of a problem.
Table 6-7 Boot-error codes
Blink codes Error
Amber battery light: blinks 1 Hz continuously Embedded Controller unable to load rmware
Caps/num lock lights = 1 blink Processor not executing code
Caps/num lock lights = 2 blinks BIOS recovery code unable to nd valid BIOS recovery image
Caps/num lock lights = 3 blinks Memory module error
Caps/num lock lights = 4 blinks Graphics controller error
Caps/num lock lights = 5 blinks System board error
Caps/num lock lights = 6 blinks Intel Trusted Execution Technology (TXT) Error
Caps/num lock lights = 7 blinks Sure Start unable to nd valid BIOS Boot Block image
Caps/num lock lights = 8 blinks Sure Start has identied a problem (Manual Recovery Policy Set)
Processor not executing code
This computer has experienced a problem due to the failure of certain code to execute, resulting in a failed
startup of the processor. The issue could be related to the processor or the system board in the computer. If the
processor is socketed, be sure that the processor is seated correctly in the socket. If this error reoccurs, refer to
General troubleshooting steps on page 59.
NOTE: The computer will attempt to notify you of this problem through a series of blinking lights. When you
attempt to turn on the computer from an “O” or “Hibernated” state, lights associated with the caps lock and
num lock keys will both blink once followed by a pause, and then continue in a repeating pattern.
120 Chapter 6 Troubleshooting guide
