2. Remove the four Torx4 M2.0×4.2 shoulder screws that secure the display panel assembly to the tablet.
3. Remove the SD card slot blank.
4. Rest and support the tablet on its top edge with the display panel toward you.
CAUTION: Use caution when separating the display panel assembly from the back cover. The internal
component cables are fragile and only allow for a limited range of motion. Failure to follow this caution can
result in damage to the internal components, their cables, and the system board.
5. Use your ngers or a case utility tool (1) or other similar thin plastic tool to separate the bottom edge of the
display panel assembly from the back cover.
Component replacement procedures 31
