To replace the DIMM, open the DIMM slot latches, and then install the DIMM. Be sure to then replace all other components
that were removed for removing the DIMM.
More information
Power down the server blade
Remove the server blade
Removing the access panel
Removing the DIMM bales
Removing and replacing an NVDIMM
CAUTION: Do not remove an NVDIMM when any LEDs on any NVDIMM in the system are illuminated. Removing an
NVDIMM when an LED is illuminated might cause a loss of data.
CAUTION: Electrostatic discharge can damage electronic components. Be sure you are properly grounded before
beginning this procedure.
CAUTION: Failure to properly handle DIMMs can cause damage to DIMM components and the system board
connector.
To identify NVDIMMs installed in the server blade, see NVDIMM identification
Prerequisites
Before replacing memory, read the memory configuration and population guidelines in the server user guide.
Procedure
1. Observe
NVDIMM relocation guidelines.
2. Power down the server blade.
3.
Remove the server blade.
4. Place the server blade on a flat, level work surface.
5. Remove the access panel (
Removing the access panel).
Removal and replacement procedures
50
