HPE ProLiant BL460c Gen10

IMPORTANT: When removing a DIMM bale, do not remove the following options when installed on the
DIMM bale:
• M.2 enablement option (left DIMM bale)
• HPE Smart Storage Battery (right DIMM bale)
IMPORTANT: When removing the right DIMM bale, use the blue pull tab to disconnect the HPE Smart
Storage Battery cable from the system board.
8. Remove both DIMM bales (Removing the DIMM bales).
9. Remove the front panel/drive cage assembly (Removing and replacing the front panel/drive cage assembly).
10. Remove the SAS/SATA or the NVMe drive backplane from the front panel/drive cage assembly.
To replace the component, reverse the removal procedure.
More information
Power down the server blade
Remove the server blade
Removing the access panel
Removing and replacing the system battery
If the server blade no longer automatically displays the correct date and time, then replace the battery that provides
power to the real-time clock. Under normal use, battery life is 5 to 10 years. This server blade uses a CR2032 battery.
Removal and replacement procedures
