For more information about battery replacement or proper disposal, contact an authorized reseller or an authorized
service provider.
More information
Power down the server blade
Remove the server blade
Removing the access panel
Removing the DIMM bales
Removing and replacing the heatsink blank
Removing the heatsink blank
Procedure
1. Power down the server blade.
2. Remove the server blade.
3. Place the server blade on a flat, level work surface.
4.
Remove the access panel.
5.
Remove the heatsink blank.
Retain the heatsink blank for future use.
More information
Power down the server blade
Remove the server blade
Removing the access panel
Replacing the heatsink blank
Procedure
1. Install the heatsink blank.
Be sure to press on the alternate corners shown until the heatsink blank snaps into place on the posts with an audible
click.
Removal and replacement procedures
74
