HPE ProLiant BL460c Gen10

Removing the HPE Smart Storage Battery
WARNING: The server blade may contain internal replaceable battery cells or battery packs. A risk of fire, burns, or
explosions exists if the battery pack is not properly handled. To reduce the risk of personal injury:
• Do not attempt to recharge the battery outside of the installed application.
• Do not expose the battery to temperatures higher than 60°C (140°F).
• Do not disassemble, crush, puncture, short external contacts, or dispose of the battery in fire or water.
• Replace only with the Hewlett Packard Enterprise spare battery designated for this product. Dispose of used
batteries according to the manufacturer's instructions and local disposal requirements.
• For battery holders (for example, coin cells), observe the correct polarity when changing the battery/cell. A
danger of explosion exists if the battery is installed incorrectly.
Procedure
1. Power down the server blade.
2. Remove the server blade.
3.
Place the server blade on a flat, level work surface.
4.
Remove the access panel.
5.
If installed, remove the direct connect SATA cable.
6.
If installed, remove the internal USB drive.
To locate the internal USB connector, see
System board components.
IMPORTANT: When removing a DIMM
bale, do not remove the following options when installed on the DIMM
bale:
• M.2 enablement option (left DIMM bale)
• HPE Smart Storage Battery (right DIMM bale)
IMPORTANT: When removing the right DIMM bale, use the blue pull tab to disconnect the HPE Smart Storage
Battery cable from the system board.
7.
Remove the right DIMM bale.
8. Remove the HPE Smart Storage Battery from the right DIMM bale.
Removal and replacement procedures
67
