4. Install the M.2 interposer board on the left DIMM bale until it clicks into place.
5.
Install the left DIMM bale.
6.
Install the access panel.
7. Install the server blade.
8. Power up the server blade.
More information
Power up the server blade
Removing and replacing an M.2 SSD
Replacing the DIMM bales
Replacing the access panel
Install the server blade
Removal and replacement procedures
56
