3. Align and install the DIMM bale.
Press down on the cable connector to fully seat the HPE Smart Storage Battery cable connector to the system board.
4.
If removed, install the direct connect SATA cable.
5. If removed, install the internal USB drive.
To locate the internal USB connector, see System board components.
6. Install the access panel.
7. Install the server blade.
8. Power up the server blade.
More information
Power up the server blade
Removing and replacing the direct connect SATA cable
Replacing the access panel
Removal and replacement procedures
