hpmont HD3N Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 96 - HD3N Series User Manual V1.1
Inverter output load loss detection fault (F20.03
- F20.05)
Ref. code Function Description Setting Range [Default]
F20.03
Detection action for inverter output load loss
0 - 4 [0]
0: Invalid, not detect.
1: Detect during running and keep running (alarm).
2: Detect during constant speed and keep running
(alarm).
3: Detect during running and stop output (fault).
4: Detect during constant speed stop output (fault).
F20.04
Detection value for inverter output load loss
0 - 100 [30%]
Defines the current value for output load loss alarm. It relates to rated current of inverter.
F20.05
Detection time for invertre output load loss
0.00 - 20.00 [1.00s]
When inverter output current < F20.04, and duration > F20.05, inverter reports E0018 fault.
• F20.04 = 0 or F20.05 = 0, inverter does not detect inverter load loss fault (E0018).
Input/output phase loss fault (F20.08
- F20.11)
Ref. code Function Description Setting Range [Default]
F20.08
The detection base of lack of input
0 - 80 [30%]
F20.09 The detection time of lack of input 1.00 - 5.00 [1.00s]
F20.08 is a percentage of rated voltage of HD3N.
When HD3N detects certain input voltage does not hit the detection base (F20.08) and exceeds the preset
detection time (F20.09), HD3N alarms E0015 fault.
•
F20.08 = 0, HD3N will not detect input phase loss fault (E0015).
F20.10 The detection base of lack of output 0 - 100 [20%]
F20.11
The detection time of lack of output
1.00 - 20.00 [3.00s]
F20.10 is a percentage of rated current of HD3N.
When HD3N detects certain output current does not hit the detection base (F20.10) and exceeds the
detection time (F20.11), HD3N alarms E0016 fault.
• F20.10 = 0, HD3N will not detect output phase loss fault (E0016).
PID fault
(F20.12 - F20.17)
Ref. code Function Description Setting Range [Default]
F20.12
PID setting lose detection value
0 - 100 [0%]
F20.13
PID setting loss detection time
0.00 - 10.00 [0.20s]
F20.12 value is a percentage of the max. setting source.
If the PID setting < F20.12 within detection time (F20.13), HD3N will alarm E0025 fault.
•
F20.12 or F20.13 = 0, HD3N will not detect PID setting loss fault (E0025).
F20.14
PID feedback loss detection value
0 - 100 [0%]
F20.15
PID feedback loss detection time
0.00 - 10.00 [0.20s]
F20.14 value is a percentage of the max. feedback source.
If the PID feedback value < F20.14 in the detection time (F20.15), HD3N will alarm E0026 fault.
• F20.14 or F20.15 = 0, HD3N will not detect PID feedback loss fault (E0026).
F20.16
Detection value at PID feedback out of the limit
0 - 100 [100%]
F20.17
Detection time at PID feedback out of the limit
0.00 - 10.00 [0.20s]
F20.16 value is a percentage of the max. feedback source.
If the PID feedback value > F20.16 in the detection time (F20.17), HD3N will alarm E0027 fault.
•
F20.16 = 100 or F20.17 = 0, HD3N will not detect PID feedback out of limit fault (E0027).
