hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3N Series User Manual V1.1 - 97 -
Fault auto
-reset function and fault relay action (F20.18 - F20.20)
Auto reset function enables HD3N to reset the fault as per the reset times and interval.
During the reset interval, HD3N stops output and it will automatically restarts
if running command is
valid.
The following faults do not have the auto reset function:
E0008: Power module fault E0021: Read / Write fault of control board EEPROM
E0010: Braking unit fault E0023: Wrong parameter setting
E0014: Current detection fault E0024: External fault
Ref. code Function Description Setting Range [Default]
F20.18
Fault auto reset times
0 - 100 [0]
F20.19
Fault auto reset interval
0.01 - 200.00 [5.00s/time]
When F20.18 = 0, it means “auto reset” is unused and the protective device will be activated.
• If no other fault is detected within 5 minutes, the auto reset count will be automatically cleared.
•
On condition of external fault reset, auto reset count will be cleared.
F20.20
Faulty relay action
00 - 11 [00]
Unit: In auto reset process
• 0: Faulty relay doesn’t act.
•
1: Faulty relay acts.
Ten: In undervoltage process
• 0: Faulty relay doesn’t act.
•
1: Faulty relay acts.
Note: relay must be set as No. 31 function.
Fault history
(F20.21 - F20.37)
Ref. code Function Description Setting Range [Default]
F20.21
NO.5 fault type
[Actual value]
F20.22
Setting frequency at NO.5 fault
F20.23
Running frequency at NO.5 fault
F20.24
DC bus vlotage at NO.5 fault
F20.25
Output voltage at NO.5 fault
F20.26
Output current at NO.5 fault
F20.27
Input terminal status at NO.5 fault
F20.28
Output terminal status at NO.5 fault
F20.29
NO.5 fault interval
F20.30
NO.4 fault type
F20.31
NO.4 fault interval
F20.32
NO.3 fault type
F20.33
NO.3 fault interval
F20.34
NO.2 fault type
F20.35
NO.2 fault interval
F20.36
NO.1 fault type
F20.37
NO.1 fault interval
F20.38
Last time fault interval
F20.22 - F20.29 record status parameters of HD3N at the last fault.
F20.30 - F20.37 record the type and interval per time of four faults before the latest. The unit of interval is
0.1 hour.
6
