hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 119 -
Ref. Code
Function Setting Range Default Unit Attribute Setting
3: Frequency
F04.24
PID parameter switching
point 1
0.0% - F04.25 0.0% 0.1%
○
F04.25
PID parameter switching
point 2
F04.24 - 100.0% 100.0% 0.1%
○
F04.27 Rpm 1 - 9999 1024 1
×
F04.28 Max. closed-loop speed 1 - 24000rpm 1500rpm 1rpm
×
F04.29 PID calculating mode
0: Do not calculate when HD3N stops
1: Calculate when HD3N stops
0 1
×
F04.30 PID dormancy selection
0: Disable
1: Enable
0 1
×
F04.31 Wakeup tolerance 0.0 - 100.0% 10.0% 0.1%
○
F04.32 Wakeup delay 0.0 - 6000.0s 0.0s 0.1s
○
F04.33 Dormancy tplerance 0.0 - 100.0% 10.0% 0.1%
○
F04.34 Dormancy delay 0.0 - 6000.0s 0.0s 0.1s
○
F04.35 Dormancy frequency 0.00Hz - max. frequency 20.00Hz 0.01Hz
○
F05: External Setting Curve Parameter (on pages 61 - 63)
F05.00
External setting curve
selection
Unit: AI1 curve
Ten: AI2 curve
Tens thousands: Pulse curve
0: Line 1
1: Line 2
2: Polyline
3: Do not dispose
33333 1
×
F05.01 Line 1 min. setting 0.0% - F05.03 0.0% 0.1%
○
F05.02
Corresponding value of
line 1 min. setting
0.0 - 100.0% 0.0% 0.1%
○
F05.03 Line 1 max. setting F05.01 - 100.0% 100.0% 0.1%
○
F05.04
Corresponding value of
line 1 max. setting
0.0 - 100.0% 100.0% 0.1%
○
F05.05 Line 2 min. setting 0.0% - F05.07 0.0% 0.1%
○
F05.06
Corresponding value of
line 2 min. setting
0.0 - 100.0% 0.0% 0.1%
○
F05.07 Line 2 max. setting F05.05 - 100.0% 100.0% 0.1%
○
F05.08
Corresponding value of
line 2 max. setting
0.0 - 100.0% 100.0% 0.1%
○
F05.09 Max. setting of polyline F05.11 - 100.0% 100.0% 0.1%
○
F05.10
Max. setting
corresponding value of
polyline
0.0 - 100.0% 100.0% 0.1%
○
F05.11
Inflection point 2 setting
of polyline
F05.13 - F05.09 100.0% 0.1%
○
A
