Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 129 -
Ref. Code
Function Setting Range Default Unit Attribute Setting
F15.28 Zero speed threshold 0.00 - upper limit frequency 0.00Hz 0.01Hz
○
F15.29 Zero speed tolerance 0.00 - upper limit frequency 0.00Hz 0.01Hz
○
F15.30 FDT1 detection mode
0: Detect according to setting
frequency
1: Detect according to output
frequency
0 1
○
F15.31 FDT1 level 0.00 - upper limit frequency 5.00Hz 0.01Hz
○
F15.32 FDT1 delay 0.00 - upper limit frequency 0.00Hz 0.01Hz
○
F15.33 FDT2detection mode
0: Detect according to setting
frequency
1: Detect according to output
frequency
0 1
○
F15.34 FDT2 level 0.00 - upper limit frequency 5.00Hz 0.01Hz
○
F15.35 FDT2delay 0.00 - upper limit frequency 0.00Hz 0.01Hz
○
F15.36 Set running times
0 - 65535h
0h: F15.36 is invalid
0h 1h
○
F15.37 Set fully counting value F15.38 - 9999 0 1
○
F15.38
Specific fully counting
value
0 - F15.37 0 1
○
F15.39
Action selection when
analogue input exceeding
limit
Unit: Action of HD3N when input
exceeding limit
0: Coast to stop
1: Emergency stop
2: Decelerate to stop
3: No action
Ten: Select analogue input terminal
0: No analogue terminal
1: Potentionmeter on keypad
2: AI1
3: AI2
Hundred: Condition for detecting
analogue exceeding limit
0: Detect all the time
1: Detect according to command
Thousand: Running selection after
exceeding
0: Do not permit auto running
1: Permit auto running
Ten thousand: Action at analogue
exceeding limit
0: Do not report external fault
(E0024)
00000 1
×
