hpmont HD3N Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
- 130 - HD3N Series User Manual V1.1
Ref. Code
Function Setting Range Default Unit Attribute Setting
1: Report external fault (E0024), can
not auto reset.
2: Report external fault (E0024), can
auto reset
F15.40
Upper limit of exceeded
analogue input
F15.41 - 100.0% 100.0% 0.1%
○
F15.41
Lower limit of exceeded
analogue input
0.0% - F15.40 0.0% 0.1%
○
F15.42
Detection time for
exceeded analogue
0.00 - 50.00s 5.00s 0.01s
○
F15.43 Terminal output delay 0.0 - 100.0s 0.0s 0.1s
○
F15.44
Detection time for
exceeded analogue at
start
0.00 - 50.00s 15.00s 0.01s
○
F16: Analogue I/O Terminal Parameters (on pages 83 - 86)
F16.00
Keypad with
potentiometer function
0: Used
1: Upper frequency setting
2: Frequency setting
3: Aux frequency setting
4: Process PID setting
5: Process PID feedback
6: Process PID regulating upper limit
7: Process PID regulating lower limit
9: Electric torque limit when motor is
forward
10: Electric torque limit when motor
is reverse
11: Re-generative torque when
motor is forward
12:Re-generative torque when motor
is reverse
13: Torque command setting
15: Upper limit frequency in torque
control
0 1
×
F16.01 AI1 function 2 1
×
F16.02 AI2 function 5 1
×
F16.05 AI1 bias -100.0 - 100.0% 0.0% 0.1%
○
F16.08 AI2 bias -100.0 - 100.0% 0.0% 0.1%
○
F16.06 AI1 gain 0.00 - 10.00 1.00 0.01
○
F16.09 AI2 gain 0.00 - 10.00 1.00 0.01
○
F16.07 AI1 filtering time 0.01 - 10.00s 0.05s 0.01s
○
F16.10 AI2 filtering time 0.01 - 10.00s 0.05s 0.01s
○
F16.17
Max. input pulse
frequency
0 - 10000Hz 10000Hz 1Hz
○
F16.18 Input pulse filter time 0.01 - 10.00s 0.20s 0.01s
○
