Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 131 -
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
F16.19 AO1 function
0: Unused
1,2: Output frequency / setting
frequency (0 - max. output
frequency)
3: Motor RPM (0 - max. output
frequency corresponding to RPM)
4: Output current (0 - twice rated
current of HD3N)
5: Output current (0 - twice rated
current of motor)
6: Torque command (0 - 3 times rated
torque of motor)
10: Output torque (0 - 3 times rated
torque of motor)
11: Output torque (0 1.2 times
rated voltage of HD3N)
12: Bus voltage (0 - 2.2 times rated
voltage of HD3N)
13: Output power (0 - twice rated
power of motor)
14: AI1 input (0 max. AI1 after
calculating)
15: AI2 input (0 - max. AI2 after
calculating)
18,19: Output frequency, setting
frequency (-1 - 1 times max. output
frequency)
20: Setting frequency (
- max.
Output frequency)
21: SCI data output (communication
data 0 - 1000 corresponding to AO
output 0.00 - 10.00V)
2 1
F16.20 AO2 function 0 1
F16.21
High-speed pulse output
function
0 1
F16.22 AO1 bias -100.0 - 100.0% 0.0% 0.1%
F16.23 AO1 gain 0.0 - 200.0% 100.0% 0.1%
F16.24 AO2 bias -100.0 - 100.0% 0.0% 0.1%
F16.25 AO2 gain 0.0 - 200.0% 100.0% 0.1%
F16.26
DO2 max. output pulse
frequency
0.1 - 10.0kHz 10.0kHz 0.1kHz
F16.27 Bias of potentionmeter -100.0 - 100.0% (LED keypad) 0.0% 0.1%
F16.28 Gain of potentionmeter 0.00 - 10.00 (LED keypad) 1.00 0.01
F17: SCI Communication Parameter (on pages 86 - 87)
F17.00 Data format
0: 1-8-2 format, no parity, RTU
1: 1-8-1 format, even parity, RTU
2: 1-8-1 format, odd parity, RTU
6: 1-8-1 format, no parity, RTU
0 1
×
