hpmont HD3N Series - Appendix A Parameters; F17: SCI Communication Parameter (on pages 86 - 87)

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
- 132 - HD3N Series User Manual V1.1
Ref. Code
Function Setting Range Default Unit Attribute Setting
F17.01 Baud rate
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
6: 57600bps
7: 76800bps
8: 115200bps
3 1
×
F17.02 Local address 0 - 247 2 1
×
F17.03 Host PC response time 0 - 1000ms 1ms 1ms
×
F17.04
Detection time at
communication timeout
0.0 - 600.0s
0.0s: Not detect communication
timeout
0.0s 0.1s
×
F17.05
Detection time at
communication error
0.0 - 600.0s
0.0s: Not detect the communication
error
0.0s 0.1s
×
F17.06
Action selection at
communication timeout
0: Coast to stop
1: Emergency stop
2: Decelerate to stop
3: Continue to run
3 1
×
F17.07
Action selection at
communication error
3 1
×
F17.08
Action selection at
communication peripheral
device fault
1 1
×
F17.09
EEPROM storage selection
under communication
read/write function
parameter
Unit: parameters storage selection
except F00.13 and F19.03
0: Do not store to EEPROM
1: Store to EEPROM
Ten: F00.13 and F19.03 storage
selection
0: Do not store to EEPROM
1: Store to EEPROM
01 1
×
F17.10
Detection time of
networking
communication timeout
0.0 - 600.0s
0.0s: Not detect communication
timeout
0.0s 0.1s
×
F18: Display Control Parameter (on pages 87 - 88)
F18.02
Set parameter 1 of run
status
0: Unuesd
1: Rated current of HD3N
3: Invertre status
4: Main setting frequency channel
5: Main setting frequency
6: Aux setting frequency
7: Setting frequency
8: Setting frequency (after Acc. /
Dec.)
9: Output frequency
8 1
○
F18.03
Set parameter 2 of run
status
7 1
○
F18.04
Set parameter 3 of run
status
9 1
○
F18.05
Set parameter 4 of run
status
13 1
○
