hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 133 -
Ref. Code
Function Setting Range Default Unit Attribute Setting
F18.06
Set parameter 5 of run
status
10 Setting Rpm
12: Input cable voltage
13: Output voltage
14: Output current
15: Torque setting
16: Output torque
17: Output power
18: DC busbar voltage
19: Input voltage of potentionmeter
20: AI1 input voltage
21: AI1 input voltage (after
calculating)
22: AI2 input voltage
23: AI2 input voltage (after
calculating)
28: DI6 terminal pulse input
frequency
29: AO1 output
30: AO2 output
31: High speed output pulse
frequency
32: Heatsink temperature
33: Setting line speed
34: Reference line speed
37: Process PID setting
38: Process PID feedback
39: Process PID deviation
40: Process PID integral value
41: Process PID output
42: External counting value
43: Input terminal status
44: Output terminal status
45: MODBUS status
46: Actual length
47: Accumulative length
48: Total time at power on (hour)
49: Total running time (hour)
14 1
○
F18.07
Set parameter 6 of run
status
18 1
○
F18.08
Set parameter 1 of stop
status
7 1
○
F18.09
Set parameter 2 of stop
status
18 1
○
F18.10
Set parameter 3 of stop
status
20 1
○
F18.11
Set parameter 4 of stop
status
22 1
○
F18.12
Set parameter 5 of stop
status
43 1
○
F18.13
Set parameter 6 of stop
status
44 1
○
F18.14 Frequency display gain 0.1 - 160.0 1.0 0.1
○
F18.15 Max. line speed 0 - 65535 1000 1
○
F18.16
Display accuracy of line
speed
0: Round number
1: One decimal
2: Two decimals
3: Three decimals
0 1
○
A
