Page #156 background image
Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 137 -
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
0: HD3N doesn’t alarm and continues
running when detecting an active
overload signal
1: HD3N alarms and stops running
when detecting an active overload
signal
Hundred: Overload detection
threshold
0: Relates to rated current of motor
(alarm E0019: motor overload)
1: Relates to rated current of HD3N
(alarm E0017: inverter overload)
Thousand: Motor type
0: Standard motor
1: Variable frequency motor
Ten thousand: Overload protection
0: Enable inverter overload
protection and motor overload
protection
1: Enable inverter overload
protection; shield motor overload
protection
2: Shield inverter overload
protection; enable motor overload
protection
3: Shield inverter overload protection
and motor overload protection
F20.01
Overload pre-alarm
detection value
20.0 - 200.0% 150.0% 0.1%
F20.02
Overload pre-alarm
detection time
0.0 - 60.0s 5.0s 0.1s
F20.03
Detection action for
inverter output load loss
0: Invalid, not detect
1: Detect during running and keep
running (alarm)
2: Detect during constant speed and
keep running (alarm)
3: Detect during running and stop
output (fault)
4: : Detect during constant speed
stop output (fault)
0 1
F20.04
Detection value for
inverter output load loss
0 - 100% 30% 1%
F20.05
Detection time for invertre
output load loss
0.00 - 20.00s 1.00s 0.01s
