Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
- 136 - HD3N Series User Manual V1.1
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
F19.32 Length fully met function
Units:
0: Outputs level signal
1: Outputs 500ms pulse
Tens:
0: Stop
1: Continue running
00 1
F19.33
Action of length when
length is met
0: Clear to 0
1: Remain
2: Continue calculating
0 1
F19.34 Action of length at stop 0 1
F19.35 Aux PID output limit 0.0 - 100.0% 100.0% 0.1%
×
F19.36 Aux PID output setting 0.0 - 100.0% 0.0% 0.1%
×
F19.37
Frequency adjustment
range
Unit: main frequency calculating
range
0: 0 - max. frequency
1: Negative max. frequency- max.
frequency
Ten: Aux frequency calculating range
0: 0 - max. frequency
1: Negative max. frequency- max.
frequency
Hundred: Resultant frequency
calculating range
0: 0 - upper limit frequency
1: Negative upper limit frequency
upper limit frequency
100 1
F19.38
Inter-phase short-circuit
detection
0: Do not detect
1: Detect
1 1
F19.39 Inout voltage selection
0: 380 - 460V
1: 260 - 460V
2: 200 - 460V
0 1
×
F19.40
Flux braking PI regulator
Kp
0 - 4000 1000 1
F19.41
Flux braking PI regulator
Ki
0 - 500 20 1
F19.44 LCD backlight display time 0.0 - 999.9min 5.0min 0.1min
F20: Fault Protection Parameters (on pages 95 - 98)
F20.00
Overload pre-alarm
detection
Unit: Overload pre-alarm detection
0: It is active all the time in running
status
1: It is active only at constant speed
Ten: Overload pre-alarm action
00000 1
