Page #154 background imageLoading...
Page #154 background image
Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 135 -
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
F19.10 Zero frequency threshold 0.00 - upper limit frequency 1.00 Hz 0.01Hz
F19.11
Action selection when
setting frequency<zero
frequency threshold
0: Runs according to frequency
command
1: Remains stop and does not output
2: Runs according to zero frequency
3: Runs at 0Hz
0 1
×
F19.12
Non-stop at instantaneous
power loss
0: Forbid non-stop at instantaneous
power loss
1: Enable non-stop at instantaneous
power loss
0 1
×
F19.13
Voltage compensation
gain for non-stop running
0.010 - 1.000 0.500 0.001
F19.15
Voltage for action
judgement at
instantaneous power loss
400 - 670V 430V 1V
×
F19.16 Restart after power failure
0: Disabled
1: Enabled
0 1
×
F19.17
Waiting time for restart
after power failure
0.00 - 10.00s 2.00s 0.01s
F19.18
Overvoltage suppression
gain
0.000 - 1.000
0.000: Forbit
0.500 0.001
F19.19 Stall overvoltage point 650 - 790V 690V 1V
F19.20 Auto current limit gain 0.000 - 1.000 0.500 0.001
F19.21
Auto current limit
threshold
20.0 - 200.0% 150.0% 0.1%
F19.23
Terminal running
command detection
Unit: terminal selection when
powered on
Ten: terminal selection after powered
on
0: Edge is valid
1: Level is valid
00 1
F19.24
Action voltage of braking
unit
630 - 750V 680V
1V
F19.25 Flux braking
0: Disabled
1: Enable
0 1
F19.26 Setting length 0 - 65535m 0m 1m
F19.27 Actual length 0 - 65535m 0m 1m *
F19.28 Length multiplying power 0.001 - 30.000 1.000 0.001
F19.29
Length correction
coefficient
0.001 - 1.000 1.000 0.001
F19.30 Axis diameter 1.00 - 100.00cm 10.00cm 0.01cm
F19.31
Pulse No. per rotate of
testing axis
1 - 9999 1 1
