hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 139 -
Ref. Code
Function Setting Range Default Unit Attribute Setting
E0005: DC bus over voltage
(in Dec process)
E0006: DC bus over voltage
(in constant speed process)
E0007: Stall overvoltage
E0008: Power module fault
E0009 :Heatsink overheat
E0010: Braking unit fault
E0012: Parameters auto-tuning fault
E0014: Current detection circuit fault
E0015: Input voltage phase loss
E0016: Output voltage phase loss
E0017: Inverter overload
E0018: Inverter output load-loss
E0019: Motor overload
E0020: Motor overheat
E0021: Read / Write fault of control
board EEPROM
E0023: Faulty setting of parameters
E0024: Fault of external equipment
E0025: PID setting loss
E0026: PID feedback loss
E0027: PID feedback out of limit
E0028: SCI communication timeout
E0029: SCI communication error
F20.22
Setting frequency at NO.5
fault
0.00 - 400.00Hz 0.00Hz 0.01Hz *
F20.23
Running frequency at
NO.5 fault
0.00 - 400.00Hz 0.00Hz 0.01Hz *
F20.24
DC bus vlotage at NO.5
fault
0 - 999V 0V 1V *
F20.25
Output voltage at NO.5
fault
0 - 999V 0V 1V *
F20.26
Output current at NO.5
fault
Actual value 0.0A 0.1A *
F20.27
Input terminal status at
NO.5 fault
0 - 0x1FF 0 1 *
F20.28
Output terminal status at
NO.5 fault
0 - 0x7FF 0 1 *
F20.29 NO.5 fault interval 0 - 6553.5 hours 0.0h 0.1h *
F20.30 NO.4 fault type 0 - 99 0 1 *
F20.31 NO.4 fault interval 0 - 6553.5 hours 0.0h 0.1h *
F20.32 NO.3 fault type 0 - 99 0 1 *
F20.33 NO.3 fault interval 0 - 6553.5 hours 0.0h 0.1h *
F20.34 NO.2 fault type 0 - 99 0 1 *
