hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix B Communication Protocol
HD3N Series User Manual V1.1 - 149 -
Status parameter (0x33) address mapping
The status parameters (0x33) are mapped as higher bytes of the register address, and the intergroup
indexes are as following:
Address Function Address Function
0x3300 Controller series 0x331C AI1input voltage (after calculating)
0x3301 Software version of DSP 0x331D AI2 input voltage
0x3303 Special sofwtware ersion of MCB 0x331E AI2 input voltage (after calculating)
0x3305 Software of keypad 0x3323 DI6 terminal pulse input frequency
0x3306 Customized serial No. 0x3324 AO1 output
0x3307 Motor and control mode selection 0x3325 AO2 output
0x3308 Rated current of inverter 0x3326 High speed output pulse frequency
0x330A Inverter status 0x332C Process PID setting
0x330B Main setting frequency channel 0x332D Process PIDfeedback
0x330C Main setting frequency 0x332E Process PID tolerance
0x330D Aux setting frequency 0x332F Process PID integral
0x330E Setting frequency 0x3330 Process PID output
0x330F Setting frequency (after calculated) 0x3331 External counting value
0x3310 Output frequency 0x3332 Input terminal status
0x3311 Setting rpm 0x3333 Output terminal status
0x3312 Running rpm 0x3334 MODBUS status
0x3313 Input cable voltage 0x3335 Actrual length
0x3314 Output voltage 0x3336 Accumulative length
0x3315 Output current 0x3337 Total power up time
0x3316 Torque setting 0x3338 Total running time
0x3317
Output torque
0x3339
Total energy consumption high bit of
motor
0x3318
Output frequency
0x333A
Total energy consumption low bit of
motor
0x3319 DC busbar voltage 0x333B Present energy consumption high bit
0x331A Input voltage of potentionmeter 0x333C Present energy consumption low bit
0x331B AI1 input voltage 0x333D Present fault
5. Special Instruction
1. Host computer cannot restore to factory setting. It can read but not write these parameters: F08
(Asyn motor parameter) and F17 (SCI parameter).
2. Host computer cannot modify F01.00 (user password). But it can write F01.00 to verify user
password. When verified, host computer access modifying function parameter of inverter. After
modifying, write invalid password into F01.00 to disable this access.
3. If many multi-function input terminals setting are the same, it may cause dysfunction. Therefore, the
user should avoid this case when modify the multi-function terminal function via the MODBUS.
B
