Chapter 5 Operation Instructions Shenzhen Hpmont Technology Co., Ltd.
- 44 - HD3N Series User Manual V1.1
Copy parameter
Only LED keypad can copy parameter.
Copy parameter from control board to keypad:
Set F01.03 = 1/2 (copy current function code to keypad parameter 1/2), keypad displays UPLd, when
copying finished, keypad will display F01.00.
Figure 5-10 Copy to keypad
Copy parameter from keypad to control board:
Set F01.02 = 2/3 (copy keypad parameter 1/2 to current function code) or F01.02 = 5/6 (the parameter
copying includes motor parameter ), keypad displays dnLd, when copying finished, keypad will
display F01.03.
Figure 5-11 Copy to control board
Note:
1. When copying to control board, it displays d FAi L which means that EEPROM storage parameters of
keypad do not mathc with function parameters of HD3N. First, copy the setting value of the correct
function code to EEPROM of keypad, and then copy to control board.
2. When copying parameter, keypad displays and flashes “E0022” (keypad EEPROM fault). It will jump to
next function code 10s later. The troubleshooting is in section 7.1 Troubleshooting, on page 101.
Hz
A V R PM %
REVFWD ALM L O/R E LOCK
Uploading p
arameters
Hz
A V RPM %
REVFWD ALM LO/ RE LOCK
Hz
A V RPM %
REVFWD ALM LO/ RE LOCK
Downloading parameters Downloading error
