Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3N Series User Manual V1.1 - 47 -
Ref. code Function Description Setting Range [Default]
d00.16
Output frequency (Hz)
[Actual value]
d00.17 Setting rpm (rpm) [Actual value]
d00.18
Runnig rpm (rpm)
[Actual value]
d00.19 Input voltage (V) [Actual value]
d00.20
Output voltage (V)
[Actual value]
d00.21 Output current (A) [Actual value]
d00.22
Torque setting (%)
[Actual value]
Display torque setting which is relative percentage of the rated torque.
d00.23
Output torque (%)
[Actual value]
Display output torque which is relative percentage of rated torque of motor.
d00.24
Output power (kW )
[Actual value]
Display present actual output power.
d00.25
DC busbar voltage (V)
[Actual value]
d00.26 Input voltage of potentionmeter (%) [Actual value]
Display input voltage of potentionmeter that is calculated by gain, bias and filter, relative percentage of 5V.
Valid when LED keypad adopted.
d00.27
AI1 input (%)
[Actual value]
Display AI1 calculated by filter, percentage of 10V.
d00.28 AI1 input (after calculating) (%) [Actual value]
Display AI calculated by gain, bias and filter, percentage of 10V.
d00.29
AI2 input (%)
[Actual value]
Display AI2 input voltage/current calculated by filter.
When AI2 selects voltage input, 0V corresponds to 0.0%, and 10V corresponds to 100.0%.
When AI2 selects current input, 0mA corresponds to 0.0%, 20mA corresponds to 100.0%.
d00.30
AI2 input (after calculating) (%)
[Actual value]
Display AI2 input voltage/current which is calculated by gain and bias.
Refer to d00.29.
d00.35 DI6 terminal pulse input frequency (Hz) [Actual value]
d00.36
AO1 output (%)
[Actual value]
When AO1 selects voltage output, 0.0% corresponds to 0V, 100.0% corresponds to 10V.
When AO1 selects 0 - 20mA current output, 0.0% corresponds to 0mA, 100.0% corresponds to 20mA.
When AO1 selects 4 - 20mA current output, 0.0% corresponds to 4mA, 100.0% corresponds to 20mA.
Refer to F16.22 and F16.23 for setting of 4 - 20mA current output.
d00.37
AO2 output (%)
[Actual value]
The relationship is same as AO1, refer to d00.36.
d00.38
High speed output pulse frequency (Hz)
[Actual value]
d00.40
Setting line speed
[Actual value]
d00.41
Reference line speed
[Actual value]
d00.44
PID setting (%)
[Actual value]
Display PID setting relative to full scale percentage.
d00.45 PID feedback (%) [Actual value]
Display PID feedback relative to full scale percentage.
d00.46
PID tolerance (%)
[Actual value]
Display PID tolerance relative to full scale percentage.
