Page #67 background imageLoading...
Page #67 background image
Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
- 48 - HD3N Series User Manual V1.1
Ref. code Function Description Setting Range [Default]
d00.47
PID integral item (%)
[Actual value]
Display PID integral item tolerance relative to percentage of max. output frequency.
d00.48
PID output (%)
[Actual value]
Display PID output relative to percentage of max. output frequency.
d00.49
External count value
[Actual value]
d00.50
Input terminal status
[Actual value]
Display input terminal status. Each bit (binary) of this parameter stands for different physical sources which
are in below table.
0: Input terminals disconnect with common terminals.
1: Input terminals connect with common terminals.
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
- - DI6 DI5 DI4 DI3 DI2 DI1
123
d00.51
Output terminal status
[Actual value]
Display output terminal status. Each bit (binary) of this parameter stands for different physical sources
which are in the below table.
0: Output terminals disconnect with common terminals.
1: Output terminals connect with common terminals.
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
- - - - - RLY1 DO2 DO1
123
d00.52
MODBUS communication status
[Actual value]
Display MODBUS communication status.
0: Normal.
1: Communication timeout.
2: Wrong data Frame head.
4: Wrong data Frame content.
d00.53
Actual length (m)
[Actual value]
d00.54
Accumulative length (km)
[Actual value]
d00.55
Total power up time (h)
[Actual value]
d00.56
Total running time (h)
[Actual value]
d00.57
Total energy consumption high bit of motor (k kW.h)
[Actual value]
d00.58
Total energy consumption low bit of motor (k kW.h)
[Actual value]
d00.59
Present energy consumption high bit (k kW.h)
[Actual value]
d00.60
Present energy consumption low bit (k kW.h)
[Actual value]
d00.61
Present fault
[Actual value]
Display 100: means under-voltage.
