hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3N Series User Manual V1.1 - 65 -
Ref. code Function Description Setting Range [Default]
F06.33
PLC phase 9 setting
000 - 421 [420]
F06.35 PLC phase 10 setting 000 - 421 [420]
F06.37
PLC phase 11 setting
000 - 421 [420]
F06.39 PLC phase 12 setting 000 - 421 [420]
F06.41
PLC phase 13 setting
000 - 421 [420]
F06.43 PLC phase 14 setting 000 - 421 [420]
F06.45
PLC phase 15 setting
000 - 421 [420]
F06.17, F06.19, F06.21, F06.23, F06.25, F06.27, F06.29, F06.31, F06.33, F06.35, F06.37, F06.39, F06.41, F06.43,
F06.45 define running frequency, direction and Acc. / Dec. time of each phase.
Unit: PLC phase frequency selection
• 0: Multi frequency commmand. Absolute frequency of each phase = setting value.
• E.g.: Absolute frequency of phase 15 = value of F06.14.
• 1: Set by F00.1. Frequency is set by F00.10.
Ten: PLC phase direction selection
• 0: Forward.
• 1: Reverse.
• 2: Set by running command, and changes if receiving external command. Runing direction = command.
• If direction can not change, HD3N runs according to the previous phase.
Hundred: PLC phase Acc. / Dec. time selection
• 0: Acc. / Dec. time 1.
• 1: Acc. / Dec. time 2.
• 2: Acc. / Dec. time 3.
• 3: Acc. / Dec. time 4.
• 4: Set by Acc. / Dec. speed.
F06.18
Phase 1 running time
0.0 - 3276.7 [5.0]
F06.20
Phase 2 running time
0.0 - 3276.7 [0.0]
F06.22
Phase 3 running time
0.0 - 3276.7 [0.0]
F06.24
Phase 4 running time
0.0 - 3276.7 [0.0]
F06.26
Phase 5 running time
0.0 - 3276.7 [0.0]
F06.28
Phase 6 running time
0.0 - 3276.7 [0.0]
F06.30
Phase 7 running time
0.0 - 3276.7 [0.0]
F06.32
Phase 8 running time
0.0 - 3276.7 [0.0]
F06.34
Phase 9 running time
0.0 - 3276.7 [0.0]
F06.36
Phase 10 running time
0.0 - 3276.7 [0.0]
F06.38
Phase 11 running time
0.0 - 3276.7 [0.0]
F06.40
Phase 12 running time
0.0 - 3276.7 [0.0]
F06.42
Phase 13 running time
0.0 - 3276.7 [0.0]
F06.44
Phase 14 running time
0.0 - 3276.7 [0.0]
F06.46
Phase 15 running time
0.0 - 3276.7 [0.0]
F06.18, F06.20, F06.22, F06.24, F06.26, F06.28, F06.30, F06.32, F06.34, F06.36, F06.38, F06.40, F06.42, F06.44
and F06.46 define the running time of eacg PLC phase.
• When the running time = 0, it means the corresponding phase is invalid.
