Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3N Series User Manual V1.1 - 75 -
Ref. code Function Description Setting Range [Default]
13 - 16: Multi-speed frequency terminal 1 – 4.
By logic combination, HD3N can run at frequency setting channel and 15 frequency.
Set 4 terminal function, HD3N can switch between frequency setting channel and 15 frequency.
Set 3 terminal function, HD3N can switch between frequency setting channel and 7 frequency.
Set 2 terminal function, HD3N can switch between frequency setting channel and 3 frequency.
Set 1terminal function, HD3N can switch between frequency setting channel and multi-speed.
K1-multi-speed frequency terminal 1, K2-multi-speed frequency terminal 2, K3-multi-speed frequency
terminal 3, K4-multi-speed frequency terminal 4.
K4
(No. 16)
K3
(No. 15)
K2
(No. 14))
K1
(No. 13)
Frequency setting
0 0 0 0
Not change
0 0 0 1
Multi frequency 1 (F06.00)
0 0 1 0
Multi frequency 2 (F06.01)
0 0 1 1
Multi frequency 3 (F06.02)
0 1 0 0
Multi frequency 4 (F06.03)
0 1 0 1
Multi frequency 5 (F06.04)
0 1 1 0
Multi frequency 6 (F06.05)
0 1 1 1
Multi frequency 7 (F06.06)
1 0 0 0
Multi frequency 8 (F06.07)
1 0 0 1
Multi frequency 9 (F06.08)
1 0 1 0
Multi frequency 10 (F06.09)
1 0 1 1
Multi frequency 11 (F06.10)
1 1 0 0
Multi frequency 12 (F06.11)
1 1 0 1
Multi frequency 13 (F06.12)
1 1 1 0
Multi frequency 14 (F06.13)
1 1 1 1
Multi frequency 15 (F06.14)
17,18: Increase(UP) / decrease(DN) frequency.
Increase or decrease frequency by terminal, equal to remote control by keypad.
Range is set by F15.12. Refer to below table.
Valid when normal running F00.10 = 1 (terminal digital setting) or aux frequency F19.00 = 2 (terminal
digital setting).
UP (No. 17) DN (No. 18)
Frequency change
0 0
Not change
0 1
Decrease
1 0
Increase
1 1
Not change
19: Clear aux setting frequency to 0.
When valid, aux frequency is cleared to 0, and setting frequency is up to main setting.
20,21: FWD/REV jog 1 command input (JOGF1 / JOGR1).
22,23: FWD/REV jog 2 command input (JOGF2 / JOGR2).
