server for an SSH user. After SFTP services are enabled on the server and the SFTP client is
connected to the server, you can operate files between the client and the server.
Networking Requirements
As shown in Figure 6-6, after SFTP services are enabled on the router functioning as an SSH
server, you can log in to the server in password, RSA, password-rsa, or all authentication mode
from a PC on the SFTP client.
Configure a user to log in to the SSH server in password authentication mode.
Figure 6-6 Networking diagram for operating files by using SFTP
PC
Network
SSH Server
Eth1/0/0
10.137.217.225/16
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure a local key pair on the SSH server to securely exchange data between the SFTP
client and the SSH server.
2. Configure VTY user interfaces on the SSH server.
3. Configure an SSH user, including user name and password.
4. Enable SFTP services on the SSH server and configure a user service type.
Data Preparation
To complete the configuration, you need the following data:
l SSH user authentication mode: password, user name: client001, password: huawei
l User level of client001: 3
l IP address of the SSH server: 10.137.217.225
Procedure
Step 1 Configure a local key pair on the SSH server.
<Huawei> system-view
[Huawei] sysname SSH Server
[SSH Server] rsa local-key-pair create
The key name will be: Host
The range of public key size is (512 ~ 2048).
NOTES: If the key modulus is greater than 512,
It will take a few minutes.
Input the bits in the modulus[default = 512]: 768
Generating keys...
.......++++++++++++
..........++++++++++++
...................................++++++++
Huawei AR1200 Series Enterprise Routers
Configuration Guide - Basic Configuration 6 Managing the File System
Issue 04 (2012-05-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
130
