Installation Manual – Antenna & Feeder System Installation
BTS3802C & RRU
Appendix B
Engineering Label of Antenna & Feeder System
B-4
ANT_00
60
12
30
Figure B-3 Jumper label (unit: mm)
B.4.3 Usage
The indoor jumper labels should be stuck to the jumpers at the points 100mm away
from the both ends. An outdoor jumper label should be stuck to a jumper at the point
100mm away from one end. Since the jumpers are short, a jumper will be attached
with a label only.
When sticking the labels, make sure that their contents faces the proper direction so
that they can be easily viewed.
