Label Color Status Description
OFF The optical module is not in
position or is powered off.
CPRI_E Red/green ON (green) The CPRI link is normal.
ON (red) The optical module receives
local alarms related to LOS.
0.5s ON, 0.5s OFF
(red)
The CPRI link is out of lock.
OFF The optical module is not in
position or is powered off.
2.2.3 Panels of the SRXU
The SRXU has a bottom panel, a cabling cavity panel, and an LED panel.
Figure 2-4 shows the panels of the SRXU.
