Huawei BTS3802C - Figure 1-9 Finished Connection of Jumpers and Directional Antenna

Installation Manual -Antenna & Feeder System Installation
BTS3802C & RRU Chapter 1 Installation Preparations
1-10
Figure 1-9 Finished connection of jumpers and directional antenna
Caution:
The spring washers and flat washers should be applied both for the antenna fixing clip and pitch angle
adjuster. The spring washes should be on the flat washers.
