Figure 3-44 Securing the attachment plate
CAUTION
When installing the attachment plate, protect the plastic housing from being scratched.
l If you find that the plastic housing is put face down when unpacking the RRU, install the
attachment plate before taking out the RRU.
l If you find that the plastic housing is put face up, lay cardboards or packing bags on the
ground. Then, take out the RRU and install the attachment plate.
Step 2 Fit the tabs on the attachment plate into the anchor slots of the mounting plate, as shown in
Figure 3-45.
3 Installing RRU and SRXU Hardware
RRU
User Guide
3-40 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Issue 01 (2008-04-18)
