Installation Manual – Antenna & Feeder System Installation
BTS3802C & RRU
Chapter 2
Installing RF Antenna & Feeder System
2-29
(1) Antenna (2) Cable tie (3) Feeder
(4) Stiffener (5) Mat of the supporting post
Figure 2-29 Installing the directional antenna at the roof (without wall)
