Installation Manual – Antenna & Feeder System Installation
BTS3802C & RRU
Chapter 3
Installing GPS Antenna & Feeder System
3-1
Chapter 3 Installing GPS Antenna & Feeder
System
3.1 About This Chapter
This chapter describes the installation of GPS antenna and feeder system, including:
z Installation Procedure
z Locating GPS Antenna
z Installing Antenna Stand on Iron Tower
z Installing Antenna Stand on Cement Base on Roof
z Installation Antenna Stand on Parapet on Roof
z Installing GPS Antenna
z Installing Lightning Arrester and Feeder
z Binding Jumpers
z Routing Feeders
z Grounding Feeder
z Feeder Test
Note:
Regarding the same contents with the installation of antenna and feeder system of mini NodeB, this
chapter will cover only the differences between the two system installations.
3.2 Installation Procedure
The installation procedure of the antenna & feeder system of GPS is shown in Figure
3-1.
