Label
Color
Status
Description
OFF
The optical module is not in
position or is powered off.
2.1.3
Panels of the RRU
The RRU has a bottom panel, a cabling cavity panel, and an LED panel.
Figure 2-2
shows the panels of the RRU.
2 RRU and SRXU Hardware
RRU
User Guide
2-4
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Issue 01 (2008-04-18)
35
37
