Table 2-2 Ports and LEDs on the panels of the RRU
No. Item Label Remarks
1 Ports at the
bottom
RX_IN/OUT Port for interconnection between
combined cabinets
RET/PWR_SRXU Port for the RET antenna or power output
to the SRXU
ANT_TX/RXA Port for main TX/RX diversity
ANT_RXB Port for RX diversity
2 Ports on the
cabling cavity
RS485/EXT_ALM Port for alarms
CPRI_E Optical ports
CPRI_W
RTN(+) Ports for power supply
NEG(-)
PGND Grounding bolt
3 LED RUN For details, refer to 2.1.2 LEDs on the
RRU.
ALM
TX_ACT
VSWR
CPRI_W
CPRI_E
2.2 SRXU Equipment
The SRXU is an extended RF interface module that provides two RX channels for RF signals.
The SRXU receives RF signals from the antenna system, down-converts the RF signals to IF
signals, and then transmits them to the RRU after amplification, analog-to-digital conversion,
digital down-conversion, matched filtering, and DAGC. The RRU forwards the signals to the
BBU or the macro NodeB.
2.2.1 Appearance of the SRXU
The SRXU features a modular structure with its ports at the module bottom and on the cabling
cavity.
2.2.2 LEDs on the SRXU
The LEDs, on the LED panel of the SRXU, indicate the running status of the SRXU.
2.2.3 Panels of the SRXU
The SRXU has a bottom panel, a cabling cavity panel, and an LED panel.
