Installation Manual – Antenna & Feeder System Installation
BTS3802C & RRU
Chapter 2
Installing RF Antenna & Feeder System
2-35
(1)
(2)
(3)
(2)
(1)
(3)
(1) C-shaped fixing clip (2) Feeder (3) Cabling rack (hexagonal steel)
Figure 2-33 Fixing the upper end of the feeder on the tower
Figure 2-34
1-for-1 Feeder fixing clips
