Table 7-6 Transmission cables installed in the BTS3900A
No. Cable One End The Other End
Connecto
r
Installation
Position
Connect
or
Installation
Position
E1 E1/T1 surge
protection
transfer
cable
DB26
connector
BBU/GTMU/E1 DB25
connector
SLPU/UELP/
INSIDE
E2 E1/T1 surge
protection
transfer
cable
DB26
connector
BBU/WMPT/E1 DB25
connector
SLPU/UELP/
INSIDE
FE1 FE/GE
surge
protection
transfer
cable
RJ-45
connector
BBU/GTMU/FE0 RJ-45
connector
SLPU/UFLP/
INSIDE (FE0)
FE2 FE/GE
surge
protection
transfer
cable
RJ-45
connector
BBU/WMPT/FE0 RJ-45
connector
SLPU/UFLP/
INSIDE (FE0)
FE3 Interconnect
ion cable
between the
FE optical
ports
LC
connector
BBU/GTMU/FE1 LC
connector
BBU/WMPT/FE1
FE4 Interconnect
ion cable
between the
FE electrical
ports
RJ-45
connector
BBU/GTMU/FE0 RJ-45
connector
BBU/WMPT/FE0
Check and ensure the secure connections of the CPRI cables, which are installed inside the
cabinets based on different configurations of the cabinets before delivery. For details about how
to remove and insert the CPRI cable, see Inserting and Removing CPRI Cables.
