Item Specications
Conducted
susceptibility (CS)
IEC 61000-4-6
0.15–80 MHz: 10 V, 80% AM (1 kHz) modulation
Surge susceptibility IEC 61000-4-5
● AC power port: horizontal 6 kV (line to line), 1.2/50
μs, 2 ohms, criterion B; vertical 6 kV (two lines to
ground), 1.2/50 μs, 2 ohms, criterion B
● Signal port (CAN, FE): dierential mode: 1.5 kV (D.
1), 10/700 μs, 15 ohms + 25 ohms, criterion B;
common mode: 4 kV (C.3), 10/700 μs, 15 ohms
+ 25 ohms/line, criterion B;
dierential mode: 1 kV
(D.1), 1.2/50 μs, 42 ohms, criterion B; common
mode: 2 kV (C.3), 1.2/50 μs, 2 ohms + 40 ohms x n/
line, criterion B
● DI&DO, RS485:
dierential mode: 4 kV (line to line),
10/700 μs, 15 ohms + 25 ohms/line, criterion B;
common mode: 4 kV (two or multiple lines to
ground), 10/700 μs, 15 ohms + 25 ohms/line,
criterion B;
dierential mode: 1 kV (line to line),
1.2/50 μs, 2 ohms + 40 ohms, criterion B; common
mode: 2 kV (two or multiple lines to ground),
1.2/50 μs, 2 ohms +40 ohms x n/line, criterion B
● Solar power port:
dierential mode: 2 kV (line to
line), 1.2/50 μs, 2 ohms, criterion B; common mode:
4 kV (single line to ground), 1.2/50 μs, 12 ohms,
criterion B
Voltage dip
IEC 61000-4-11
● Voltage interruption (> 95% decrease) for 10 ms:
performance grade B
● Voltage interruption (> 95% decrease) for 20 ms:
performance grade B
● Voltage dip (> 30% decrease) for 500 ms:
performance grade C
● Voltage interruption (> 95% decrease) for 5000 ms:
performance grade C
iSitePower-M (MAP05A1, MAB05B1)
User Manual A Technical Specications
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 98
