5 Application Scenarios
The iSitePower-M is mainly used in houses, apartments, shops, and business
outlets. Based on
dierent energy inputs, the application scenarios are classied
into six types.
● Solar-only scenario
● Grid scenario
● Genset-grid hybrid scenario
● Solar-grid hybrid scenario
● Solar-genset hybrid scenario
● Solar-grid-genset hybrid scenario
5.1 Solar-Only Scenario
NO TICE
Do not connect optimizers to the system in the solar-only scenario. Otherwise, the
system may fail to start.
Figure 5-1 Solar-only network diagram (one product)
iSitePower-M (MAP05A1, MAB05B1)
