Huawei iSitePower-M User Manual

Type Tools and Instruments
Hydraulic pliers Heat-shrink
tubing
Heat gun
PPE
Safety gloves Safety goggles Anti-dust mask
Safety boots
- -
6.1.3 Determining the Installation Position
Basic Requirements
● Do not install the product in a position where it is easy to touch because the
temperature of the chassis and heat dissipater is high when it is running.
● Do not install the product in areas with
ammable or explosive materials.
● Do not install the product outdoors in salt areas because it may corrode and
cause
res. A salt area refers to the region within 500 m from the coast or
prone to sea breeze. The regions prone to sea breeze vary with weather
conditions (such as typhoons and monsoons) or terrains (such as dams and
hills).
● Do not install the product in a position where children can touch it.
Installation Angle Requirement
The product can be ground-mounted and wall-mounted. The installation angle
requirement is as follow:
● Do not install the product at forward tilted, back tilted, side tilted, horizontal,
or upside down positions.
iSitePower-M (MAP05A1, MAB05B1)
User Manual 6 System Installation
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 43

Huawei iSitePower-M Specifications

General

Storage Temperature	-40°C to +70°C
Product Name	Huawei iSitePower-M
Type	Power System
Efficiency	≥96%
Output Voltage	-48 V DC
Operating Temperature	-40°C to +55°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 4000 m
Cooling Method	Forced Air Cooling
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature
Certifications	CE, UL, TUV
Input Voltage Range	85 V - 300 V AC
